Siglent SDS7000A-CT-100BASE-T1 compliance test (software)

The SDS7000A-CT-100BASE-T1 option enables the decoding and analysis of 100BASE-T1 automotive Ethernet signals for the SDS7000A series digital oscilloscopes. Key features include:

1. 100BASE-T1 Ethernet Decoding: Decodes 100BASE-T1 Ethernet frames, commonly used in automotive Ethernet applications, displaying data, addressing, and protocol details for effective network analysis.
2. Triggering on Ethernet Frames: Supports advanced triggering options to capture specific frames or events, such as errors or specific data packets, facilitating precise network debugging.
3. Error Detection: Identifies and flags issues such as CRC errors or frame misalignment in 100BASE-T1 signals, helping to quickly resolve communication problems.
4. Protocol Analysis: Provides detailed analysis of the Ethernet layer, making it ideal for performance monitoring and troubleshooting of in-vehicle networks and automotive communication systems.

This option is crucial for engineers working with automotive Ethernet systems, particularly in modern vehicle networks and advanced driver-assistance systems (ADAS)​
