A built-in precision adjustment wheel allows the spacing between probe tips to be adjusted from 0 mm to 6.5 mm, making it easy to probe different PCB trace spacings, connectors, or test points without custom fixtures. This feature significantly reduces test setup time and increases measurement efficiency in the lab.

The probe provides a 100 Ω differential impedance, making it ideal for differential transmission line measurements and signal integrity testing. It connects via SMA connectors, ensuring compatibility with common RF test setups including vector network analyzers, RF signal generators, and measurement cables.

The ADP-18 is designed for durability and repeatable measurements. Even after more than 100 continuous measurement cycles, the probe maintains excellent repeatability with ≤2% variation, ensuring stable and reliable test results.

Engineers working on high-speed digital electronics, RF modules, microwave circuits, and impedance characterization will appreciate the flexibility and precision offered by the ADP-18 adjustable probe.

Key Features

• Bandwidth up to 18 GHz for RF and microwave measurements

• Adjustable probe spacing (0 – 6.5 mm) for flexible PCB probing

• 100 Ω differential impedance ideal for differential signal analysis

• SMA probe connector for easy integration with RF measurement systems

• Excellent repeatability ≤2% after 100 test cycles

• Compatible with vector network analyzers, oscilloscopes, and RF test setups

• Robust mechanical design for repeated laboratory use

• Suitable for signal integrity and impedance measurements
