Siglent SDG8000A-DCAMP DC amplified output option

Siglent SDG8000A-DCAMP DC amplified output option
€1,880.00

The SDG8000-DCAMP option adds a high-performance DC-coupled amplifier to your SDG8000A Series Arbitrary Waveform Generator. It delivers exceptional bandwidth from DC to 1 GHz, high voltage swing up to ±20 V, ultra-low noise, and excellent DC accuracy — ideal for power electronics testing, semiconductor device characterization, automotive sensor simulation, medical device testing, and high-voltage signal generation.

SDG8000-DCAMP Option | SIGLENT
OPTIONAL UPGRADE

SDG8000-DCAMP

High-performance DC-coupled amplifier option for the SDG8000A Series Arbitrary Waveform Generator.

High-Performance DC Amplifier

The SDG8000-DCAMP option adds a high-performance DC-coupled amplifier to your SDG8000A Series generator. It delivers exceptional bandwidth, low noise, and high voltage swing, making it ideal for applications that require clean DC to high-frequency signal amplification with precise control.

This option is widely used in power electronics testing, semiconductor device characterization, automotive sensor simulation, medical device testing, and high-voltage signal generation. Whether you need to drive high-capacitance loads or generate precise low-frequency to high-frequency waveforms with high amplitude, the DCAMP option provides the performance and flexibility required for demanding applications.

Key Benefits

✓
Wide Bandwidth — DC to 1 GHz bandwidth with excellent flatness and phase response.
✓
High Voltage Swing — Up to ±20 V output with low distortion and high current drive capability.
✓
Ultra-Low Noise — Extremely low noise floor for sensitive measurements and high-fidelity signal generation.
✓
Excellent DC Accuracy — High DC precision with low offset and drift for accurate DC-coupled applications.
✓
High Current Drive — Capable of driving capacitive and resistive loads with fast settling time.

What You Get

DC to 1 GHz Bandwidth

Wide frequency range from DC to 1 GHz with excellent amplitude flatness and minimal phase distortion.

High Voltage Output

Up to ±20 V output swing with high current drive capability for demanding loads.

Ultra-Low Noise & Distortion

Extremely low noise and harmonic distortion for high-fidelity signal generation and sensitive measurements.

Technical Specifications

Feature Specification
Bandwidth DC to 1 GHz (-3 dB)
Output Voltage ±20 V (into 50 Ω)
Output Current Up to ±400 mA peak
Noise Density < 5 nV/√Hz (typical)
DC Offset Accuracy ±0.1% of full scale
Settling Time < 5 ns to 0.1%
Harmonic Distortion < -60 dBc (typical)

Ideal For

Power Electronics Testing • Semiconductor Device Characterization • Automotive Sensor Simulation • Medical Device Testing • High-Voltage Signal Generation • Capacitive Load Driving
