Siglent SDG8000-ACAMP AC Amplified Output option

Siglent SDG8000-ACAMP AC Amplified Output option
€4,480.00

The SDG8000A-ACAMP option adds a high-bandwidth AC-coupled amplifier to your SDG8000A Series Arbitrary Waveform Generator. It delivers exceptional performance from 10 kHz to 5 GHz with high voltage swing, excellent linearity, and low noise — ideal for RF testing, 5G/6G component characterization, high-speed serial validation, radar signal simulation, and advanced communications testing.

OPTIONAL UPGRADE

SDG8000A-ACAMP

High-bandwidth AC-coupled amplifier option for the SDG8000A Series Arbitrary Waveform Generator.

High-Bandwidth AC Amplifier

The SDG8000A-ACAMP option adds a high-bandwidth AC-coupled amplifier to your SDG8000A Series Arbitrary Waveform Generator. It delivers exceptional performance from 10 kHz to 5 GHz with high voltage swing, excellent linearity, and low noise.

It is widely used in RF testing, 5G/6G component characterization, high-speed serial validation (PCIe, 800G Ethernet), radar signal simulation, and advanced communications testing. The ACAMP option provides the bandwidth and performance required for next-generation high-frequency applications.

Key Benefits

✓
Ultra-Wide Bandwidth — 10 kHz to 5 GHz with excellent flatness and phase response.
✓
High Voltage Swing — Up to ±10 V output with excellent linearity and low distortion.
✓
Excellent Linearity — Very low harmonic distortion for accurate high-frequency signal generation.
✓
Low Noise Performance — Optimized for high-frequency applications with minimal noise contribution.
✓
Ideal for RF & High-Speed — Perfect for 5G, radar, high-speed serial, and advanced communications testing.

What You Get

10 kHz – 5 GHz Bandwidth

Ultra-wide frequency range optimized for high-frequency and RF applications.

High Voltage Output

Up to ±10 V output swing with excellent linearity and low distortion.

Low Noise & High Linearity

Optimized for high-frequency applications with minimal noise and distortion.

Technical Specifications

Feature Specification
Bandwidth10 kHz to 5 GHz
Output Voltage±10 V (into 50 Ω)
Output CurrentUp to ±200 mA peak
Noise Density< 8 nV/√Hz (typical)
Harmonic Distortion< -55 dBc (typical)
Settling Time< 3 ns to 0.1%
AC Coupling10 kHz cutoff frequency

Ideal For

RF Testing • 5G/6G Component Characterization • High-Speed Serial Validation • Radar Signal Simulation • Advanced Communications Testing • PCIe & 800G Ethernet
