Siglent SDG8000-IQ IQ Vector Signal Generation Function option

Siglent SDG8000-IQ IQ Vector Signal Generation Function option
€6,080.00

The SDG8000A-IQ option adds advanced I/Q modulation and vector signal generation capabilities to your SDG8000A Series Arbitrary Waveform Generator. It supports a wide range of digital modulation formats including QAM, PSK, ASK, FSK, and custom I/Q waveforms — ideal for 5G/6G, LTE, WiFi, Bluetooth, and other modern wireless communication testing and development.

OPTIONAL UPGRADE

SDG8000A-IQ

Advanced I/Q Modulation & Vector Signal Generation Option for the SDG8000A Series Arbitrary Waveform Generator.

Advanced I/Q Modulation & Vector Signal Generation

The SDG8000A-IQ option adds advanced I/Q modulation and vector signal generation capabilities to your SDG8000A Series Arbitrary Waveform Generator. It supports a wide range of digital modulation formats including QAM, PSK, ASK, FSK, and custom I/Q waveforms.

It is widely used for 5G/6G, LTE, WiFi, Bluetooth, and IoT testing, wireless communication development, vector signal analysis, and baseband to RF up-conversion. The IQ option provides the flexibility and performance needed for modern wireless communication testing and development.

Key Benefits

✓
Wide Range of Modulation Formats — Support for QAM (16/64/256), PSK, ASK, FSK, and custom I/Q waveforms.
✓
High Bandwidth I/Q — Up to 2 GHz modulation bandwidth for wideband applications.
✓
Custom I/Q Waveforms — Load and play custom I/Q data from files for maximum flexibility.
✓
Seamless Integration — Works seamlessly with SigIQPro software for advanced signal creation.
✓
Ideal for Modern Wireless — Perfect for 5G NR, LTE, WiFi 6/7, Bluetooth, and IoT device testing.

What You Get

Wide Range of Modulation Formats

Support for QAM (16/64/256), PSK, ASK, FSK, and custom I/Q waveforms.

High Bandwidth I/Q Modulation

Up to 2 GHz modulation bandwidth for wideband 5G and WiFi 6/7 applications.

SigIQPro Software Support

Seamless integration with SigIQPro for advanced signal creation and analysis.

Technical Specifications

Feature Specification
Modulation BandwidthUp to 2 GHz
Supported FormatsQAM (16/64/256), PSK, ASK, FSK, custom I/Q
I/Q Data RateUp to 1.25 GSa/s per I/Q channel
Custom Waveform SupportLoad custom I/Q data from files
Software IntegrationSigIQPro software for advanced signal creation
Output InterfaceSMA (single-ended / differential)
Compatible ModelsSDG8002A and SDG8004A

Ideal For

5G/6G Testing • LTE & 5G NR • WiFi 6/7 Validation • Bluetooth & IoT • Wireless Communication Development • Vector Signal Analysis
