Siglent SNA5000-TDR — Enhanced TDR / TDT time-domain option (SNA5000X-E / SNA5000A)
Software licence adding advanced TDR and TDT to the Siglent SNA5000 vector network analyzers — pinpoint faults and impedance discontinuities in cables, PCB traces and connectors, with eye-diagram and jitter analysis. Activated by key, no hardware.
Enhanced Time-Domain / TDR
The SNA5000-TDR option adds advanced Time-Domain Reflectometry (TDR) and Time-Domain Transmission (TDT) to the SNA5000 vector network analyzers. It precisely locates impedance discontinuities, faults and reflections in cables, PCB traces, connectors and high-speed interconnects.
By transforming frequency-domain S-parameters into the time domain, TDR gives clear, intuitive insight into signal-integrity issues — turning the VNA into a powerful fault-analysis and interconnect-characterisation platform that reduces debug time and improves design confidence.
What it adds
Full TDR / TDT
Analyse impedance vs. distance, reflections and transmission with high spatial resolution.
Fault & discontinuity location
Pinpoint opens, shorts, impedance mismatches, vias, connectors and cable defects.
Advanced time-domain tools
Time-domain gating, windowing, peeling and electrical-delay compensation.
Differential & single-ended
Ideal for high-speed serial links, differential pairs and controlled-impedance PCBs.
Eye diagram & jitter
Simulate eye diagrams and analyse jitter for high-speed digital signals.
Seamless VNA integration
Share calibration, markers and setups between frequency- and time-domain modes.
Where it is used
Compatibility & activation
Compatible instruments
Siglent SNA5000X-E (SNA5003X-E, SNA5006X-E) and SNA5000A series vector network analyzers.
How it is supplied
Delivered electronically and activated on the instrument with a licence key — no hardware to install. Excluded from the 14-day EU return right once the key has been issued.
Add SNA5000-TDR to your SNA5000X-E
In EU stock with expert support. Not sure which options you need? We'll help you configure the right SNA5000X-E and licences.
