Siglent SSU5501A DC-50 GHZ including one SPDT Mechanical Switch

NEW
€4,286.25

Siglent's new SSU5501A mechanical switch has a frequency range up to 50 GHz. The SSU5501A has compact design, excellent RF characteristics, low insertion loss, great impedance matching and extraordinary short switching time. It contains 1 independent single-pole double-throw mechanical switch with 2.4mm connectors.

In order to meet the multi-port test requirements of microwave and millimeter wave systems, SIGLENT has introduced SSU5000A series mechanical switches with frequency range up to 50 GHz. The SSU5000A has compact design, excellent RF characteristics, low insertion loss, great impedance matching and extraordinary short switching time. It contains 1-4 independent single-pole double-throw mechanical switches with SMA or 2.4 mm connectors, or single-pole six-throw mechanical switches.

Compact Design, Fast Measurement

Siglent SSU5101A Key Features

    • Maximum frequency: 50 GHz.
    • 1 SPDT switch
    • SCPI Controllable via VISA and EasySSU software
    • USB Connectivity
    • Size: W×H×D=153×62.4×137.5mm
    • RF connector: 2.4mm female
    • SPDT is a Single Pole, Dual Throw switch where 1 common terminal is switched to 1 of the 2 numbered terminals.

    Standard Accessories:

    1 x User manual

    1 x Power cord

    1 x USB Cable

    Optional Accessoires:

    Siglent SSU5000A Series User Manual
    PDF – 1,5 MB 33 downloads
    Siglent SSU5000A Series Datasheet
    PDF – 1,2 MB 33 downloads
